Nomix PTFE PPS P84 Glass fiber Pleated Round Shape Filter Cages Widely Used In Dust Removal Industry
1. Introduction
Dust bag is a common dust removal equipment, which is composed of several cloth cylinders. Its main materials are synthetic fibers such as polyester fiber, polypropylene fiber and inorganic fibers such as glass fiber. These materials are characterized by high temperature resistance, corrosion resistance, abrasion resistance and so on, so they are very suitable for use in the field of dust removal.
The working principle of dust bag is to utilize the filtering effect to retain the dust and other particles in the air on the surface of the bag, so that the purified gas flows out. In the process of use, the polluted air enters into the dust collector, after pretreatment, it enters into the bag room, after filtering through the dust bag, the purified gas is discharged from the upper part of the bag room, and the dust and other particles are retained on the surface of the bag, and then cleaned up by the cleaning machine for re-use.
2. Classification:
(1) High temperature resistant needle felt
Application: Compared with other filtration materials, the abrasion resistance, bending resistance and peeling strength of glass fiber filtration materials are significantly improved. The filtration speed can reach more than 1.0m/min, and the running resistance is low. Mace filter material is widely used in iron and steel, non-ferrous smelting, chemical industry, carbon black, building materials, electric power and other sectors. Suitable temperature: below 260.
(2) Glass fiber dust bag
Usage: The filter material has excellent alkali resistance, fully suitable for filtering alkali flue gas, the filter material is not subject to corrosion. Suitable temperature: 80-260.
(3) Metas dust bag:
Uses: a special process is used to wrap a dense polytetrafluoroethylene (ptfe0) protective layer on the surface of each yarn of the glass fiber filter cloth, so that the filter material has good resistance to acid and alkali, corrosion, high temperature, friction and bending resistance, the surface is smooth and hydrophobic, and the surface of the filter cloth can not be covered with dust. Use temperature: long-term working temperature 260, short-term temperature 300.
(4) Anti-static dustproof bag:
Use: In general, when the concentration of industrial dust reaches a certain level, if the electrostatic discharge spark or external ignition, such as surface dust, coal dust and chemical dust, it is easy to cause explosions and fires. Suitable temperature: 80-130.
(5) P84 high temperature resistant needle punched filter felt:
Usage: high temperature resistant, can be used for a long time below 260℃, and has good chemical resistance. It has very significant filtering effect on dusty gas with acid and alkali characteristics, which makes it have higher dust removal efficiency in waste incineration industry.
(6) PPS high temperature resistant dust bag:
Use: With complete strength and internal chemical resistance, it can maintain good filtration performance in harsh environment and achieve ideal service life.
(7) Fluoromax dust bag:
Uses: It has the advantages of high temperature resistance, acid and alkali corrosion resistance, abrasion resistance and bending resistance. It is easy to remove dust, water and oil repellent. It can capture high air volume and high concentration of dust. It overcomes the characteristics of other chemical fiber elongation and low temperature resistance, and the price is cheaper than other high temperature resistant filter media. It is suitable for temperature 80-230.
3. For example:
| Product Name | FMS | Flomax Coated Filter Media |
| Fibre | P84+glass fibre | P84+glass fibre |
| Base cloth | High Strength Glass Fiber | High Strength Glass Fiber |
| Weight(g/㎡) | 850 | |
| Continuous use temperature(℃) | 280 | |
| Instantaneous use temperature(℃) | 300 | |
| Breaking strength (N/5*20cm) | warp direction | >1800 |
| | weft direction | >1800 |
| Elongation at break(%) | warp direction | <10 |
| | weft direction | <10 |
Air permeation
(m3/m2*min) | 10~15 | 3~6 |
| ir speed(m/min) | <1.0 | <0.8 |
| Application | High temperature resistance, good corrosion resistance, general wear resistance, suitable for filtering low wind speed, small and medium-sized cement kilns. | High temperature resistance, good corrosion resistance, general wear resistance, suitable for filtering low wind speed, small and medium-sized cement kilns. |
4. FAQ
Q: Are you a trading company or a manufacturer?
A: We are a manufacturing company. We are a professional manufacturer of dust removal and conveying equipment with more than 20 years of production.
Q: Where is your factory located?
A: The factory is located in Hebei, China, 50 minutes by rail from Beijing.
Q: Do you offer OEM services?
A: Yes. Any required logo is available.
Q: What is the production capacity of your company?
A: Our factory covers an area of more than 20,000 square meters and produces 2,000 machines a year.
Product Tags:
|
|
Nomix PTFE PPS P84 Glass Fiber Pleated Dust Collector Bags Round Shape In Dust Removal Industry Images
|
