Cement Plant Coal Mill Anti Static Dust Collector Filter Bag Easy cleaning

  • 1
  • 2
  • 3

Brand Name : QiaoDa

Model Number : 133*2500

Certification : YES

Place of Origin : China

MOQ : 8PC

Price : $4.8/PC

Payment Terms : T/T

Supply Ability : 20000 units per month

Delivery Time : 7 word days

Packaging Details : Woven bag packaging

Material : Polyester + conductive fiber/Polyester base cloth

Filtration Efficiency : 99%

Chemical Resistance : Strong

Collar Type : Snap Band, Flange, Cuff

Bag Shape : Round, Oval, Flat

Air Permeability : Good

Surface Treatment : Singed, Calendered, Heat Set

Performance : Easy cleaning

Customization : Available

thickness : 1.8mm

Air permeability : 15(m3/m2·min)

Dust Holding Capacity : High

Size : Customized

Application : Cement, Steel, Power Generation, Chemical, Food Processing

Contact Now

Cement plant coal mill dust collector anti-static dust collector filter bag

Our company absorbs and digests foreign technology, and develops and produces

anti-static needle felt dust collector filter bags according to the needs of domestic

BF gas coal mill dust collection and cement mill dust collection and other industries.
In addition to the process of producing ordinary needled felt, the production of antistatic

filter cloth also requires the incorporation of conductive fiber yarn in the warp of ther

base cloth for the production of needled felt or the mixing of conductive fiber and other

conductive materials in the chemical fiber.
After the concentration of general industrial dust reaches a certain degree (that is, the

explosion limit), such as electrostatic discharge sparks or external ignition and other

factors, it is easy to lead to explosion and fire. For example, face dust, chemical dust,

coal dust, etc. have the possibility of explosion in case of electrostatic discharge. In the

field of bag dust removal, if these dust need to be collected by cloth bags, it is required

that the filter material made of dust bags has anti-static properties.

material Polyester + conductive fiber/Polyester base cloth
weight(g/m2) 500
thickness(mm) 1.80
Air permeability(m3/m2·min) 15
Breaking strength (N/5×20cm) >800 >800
>1200 >1200
Elongation at break(%) <35 <35
<55 <55
Breaking strength (Mpa/min) 2.40
Continuous operating temperature(℃) ≤130
Short-time operating temperature(℃) 150
Surface resistance(Ω) 4.8×109
Volume resistance(Ω) 8.7×109
Friction potential(V) 250
Friction potential (mean)(V) 183
Acid resistance good
Alkali resistance good
Abrasion resistance good
Hydrolytic stability good
